SpringBoot 数据库事务注解使用规范
数据库事务注解使用规范
事务的启动机制
在进入@Transactional注解方法后即获取数据库连接，待首次数据库操作时开启事务，方法结束后提交或回滚并归还连接。但当方法处理时间较长时候，由于方法不能快速结束，导致数据库连接池无法及时归还，极易出现应用耗尽数据库连接池问题，进而导致系统崩溃。
使用规范
对大事务进行优化，针对内存耗时操作、远程http请求等非数据库操作，建议放到@Transactional注解方法的外部，避免过早或过长时间占用数据库连接，减少数据库大事务风险，避免客户端数据库连接池连接不足的问题
事务注解@Transactional禁止放在java类维度，避免无谓的事务封装
禁止在纯查询操作方法上使用事务注解
明确事务注解仅对public方法有效，protected、private方法上使用@Transactional均无效
并且非事务方法调用同类内部采用 @Transactional 修饰的方法时，事务不会生效，异常不会触发回滚
严禁在事务方法内捕获异常而不抛出，如采用@Transactional修饰方法
当研发自行添加了try/catch捕获异常且未抛出异常时，@Transactional 无法自动回滚
避免过早或过长时间占用数据库连接
对大事务进行优化，针对内存耗时操作、远程http请求等非数据库操作，建议放到@Transactional注解方法的外部，避免过早或过长时间占用数据库连接，减少数据库大事务风险，避免客户端数据库连接池连接不足的问题
反例
问题：整个方法被 @Transactional 包裹，数据库连接从开始到结束一直被占用，即使中间没有 DB 操作。可能导致连接池耗尽。
@Service
public class OcrService {
@Autowired
private OcrServiceMapper ocrServiceMapper;
@Autowired
private RestTemplate restTemplate;
@Transactional
public void insert(OcrPojo ocrPojo) {
// 1. 耗时的内存操作（不应该在事务中）
heavyInMemoryProcessing();
// 2. 远程调用（不应该在事务中）
restTemplate.postForEntity("https://api.example.com/getOcr", ocrId, String.class);
// 3. 保存 ocr 信息（DB 操作）
ocrServiceMapper.insert(ocrPojo);
// 事务直到这里才提交，连接长时间被占用 ❌
}
}
正例
拆分事务，非 DB 操作移出事务
@Service
public class OcrService {
@Autowired
private DemoService demoService;
@Autowired
private RestTemplate restTemplate;
public void buildInsert(OcrPojo ocrPojo) {
// 第一步：非事务操作（内存处理 + 远程调用）
heavyInMemoryProcessing();
restTemplate.postForEntity("https://api.example.com/getOcr", ocrId, String.class);
// 第二步：在独立事务中保存ocr
demoService.insert(ocrPojo);
}
}
@Service
public class DemoService {
@Autowired
private OcrServiceMapper ocrServiceMapper
@Transactional
public void insert(OcrPojo ocrPojo) {
ocrServiceMapper.insert(ocrPojo);
}
}
禁止类维度事务注解
事务注解@Transactional禁止放在java类维度，避免无谓的事务封装
反例
问题：@Transactional 注解不应随意加在 Java 类的维度（即类级别）上，尤其是当类中包含多个方法，且并非所有方法都需要事务时。这样做容易导致不必要的事务封装，进而引发性能问题或意外的事务传播行为。
@Service
@Transactional
public class OcrService {
public void insert(OcrPojo ocrPojo) {
// 保存ocr（需要事务）
// ...
}
public void demo() {
// 纯远程调用，无需事务 ❌ 却被事务包裹
restTemplate.post(...);
}
public String selectOcrById(String id) {
// 查询ocr操作，无需事务 ❌ 却被事务包裹
return ocrInfo;
}
}
正例
将 @Transactional 添加到具体需要事务的方法上
@Service
public class OcrService {
@Transactional
public void insert(OcrPojo ocrPojo) {
// 保存ocr（需要事务）
// 只有这个方法需要完整事务
}
public void demo() {
// 无事务，避免占用数据库连接
restTemplate.post(...);
}
public String selectOcrById(String id) {
// 无事务，避免占用数据库连接
return ocrInfo;
}
}
禁止在纯查询操作方法上使用事务注解
反例
问题：
纯查询操作被纳入事务，占用数据库连接；
在高并发场景下，可能导致连接池耗尽；
事务日志记录、事务管理器介入，增加系统开销。
@Service
public class OrderService {
@Transactional
public Order findById(Long id) {
return orderRepository.findById(id);
}
}
正例
避免占用连接
@Service
public class OrderService {
public Order findById(Long id) {
return orderRepository.findById(id);
}
}
明确事务注解仅对public方法有效
@Transactional 注解仅对 public 方法有效，这是 Spring 基于代理机制实现事务控制的一个重要限制
Spring 的 @Transactional 是通过 AOP 代理（JDK 动态代理或 CGLIB）实现的。当方法调用通过代理对象进入时，Spring 才能拦截并开启事务上下文。如果方法不是 public 的，代理机制将无法正常工作，导致事务不生效。
@Service
public class OrderService {
// ❌ protected 方法：事务不生效
@Transactional
protected void updateOrderProtected(Order order) {
orderRepository.save(order);
}
// ❌ private 方法：事务不生效，且代理完全无法拦截
@Transactional
private void logOperation() {
// 记录日志操作
}
// ❌ package-private（默认访问级别）：事务不生效
@Transactional
void sendNotification() {
restTemplate.post(...);
}
}
内部自调用也无法触发事务
非事务方法调用同类内部采用 @Transactional 修饰的方法时，事务不会生效，异常不会触发回滚
Spring 的 @Transactional 是通过 AOP 代理实现的。只有当方法调用来自类的外部（即通过代理对象调用）时，事务拦截器才会生效。如果是在类内部通过 this 直接调用，会绕过代理，导致事务失效
反例
@Service
public class OrderService {
@Transactional
public void createOrder(Order order) {
orderRepository.save(order);
}
// 非事务方法调用同类中的事务方法
public void processOrder(Order order) {
createOrder(order); // ❌ 通过 this.createOrder() 直接调用，事务不生效
}
}
正例
推荐做法：将事务方法拆分到不同类中，职责分离，事务控制更清晰。
@Service
public class OrderService {
@Autowired
private DemoService demoService;
public void processOrder(Order order) {
// ✅ 跨类调用，事务生效
demoService.createOrder(order);
}
}
@Service
class DemoService {
@Transactional
public void createOrder(Order order) {
orderRepository.save(order);
}
}
严禁在事务方法内捕获异常而不抛出
严禁在 @Transactional 修饰的事务方法中捕获异常后不重新抛出，否则会导致 Spring 事务无法感知异常，从而无法触发回滚，造成数据不一致。
Spring 的声明式事务（@Transactional）是基于代理的。它通过拦截方法的异常抛出来判断是否需要回滚。如果异常被 try-catch 捕获并“吞掉”（即不抛出），Spring 会认为方法执行成功，从而提交事务，即使内部出错了
反例
捕获异常但未抛出，即使 paymentService.charge() 抛出异常，由于被 try-catch 捕获且未重新抛出，Spring 会认为方法执行成功，事务正常提交，但实际业务已失败，导致数据不一致。
@Service
public class OrderService {
@Autowired
private OrderRepository orderRepository;
@Autowired
private PaymentService paymentService;
@Transactional
public void createOrder(Order order) {
orderRepository.save(order);
try {
paymentService.charge(order.getAmount());
} catch (Exception e) {
// ❌ 错误：捕获了异常但没有抛出，事务不会回滚
log.error("支付失败：", e);
// 没有 throw，事务正常提交
}
}
}
正确做法一
捕获后手动回滚
如果你必须捕获异常并处理，应主动标记事务回滚：
@Transactional
public void createOrder(Order order) {
orderRepository.save(order);
try {
paymentService.charge(order.getAmount());
} catch (Exception e) {
log.error("支付失败：", e);
// ✅ 抛出异常，触发回滚
throw new RuntimeException("支付失败，事务将回滚", e);
}
}
正确做法二
使用 @Transactional(rollbackFor = Exception.class) 明确回滚策略
默认情况下，Spring 事务只对 RuntimeException 和 Error 自动回滚，对 checked exception（如 IOException）不回滚。使用 rollbackFor 可以扩展回滚范围。
@Transactional(rollbackFor = Exception.class)
public void createOrder(Order order) throws PaymentException {
orderRepository.save(order);
// 抛出 checked exception 也能回滚
paymentService.charge(order.getAmount());
}
正确做法三
捕获异常后选择性处理，再抛出自定义异常
@Transactional(rollbackFor = BusinessException.class)
public void createOrder(Order order) {
orderRepository.save(order);
try {
paymentService.charge(order.getAmount());
} catch (PaymentException e) {
log.error("支付异常", e);
// ✅ 抛出被事务识别的异常
throw new BusinessException("支付失败", e);
}
}
正确做法四
不想抛出异常，可以手动回滚事务
@Transactional
public void createOrder(Order order) {
orderRepository.save(order);
try {
paymentService.charge(order.getAmount());
} catch (Exception e) {
log.error("支付失败，手动回滚", e);
// 手动回滚
TransactionAspectSupport.currentTransactionStatus().setRollbackOnly();
}
}
-
-
Spring Boot 轻量级 API 网关设计
目标
实现了一个基于 SpringBoot 的轻量级 API 防火墙，通过拦截器机制提供实时防护能力。对所有 API 请求进行“前置检查“，支持配置IP白名单、黑名单，白名单优先级更高。系统采用 Guava Cache 实现高性能内存缓存，支持 QPS 限制。
技术选型
数据库：postgresql + 通用 mapper tk.mybatis
缓存：Guava Cache
SpringBoot： 4
JDK：21
对于分布式场景，后续可以扩展 Redis + Lua 实现统一限流；但在本文场景下，先聚焦 单机轻量化防护。
核心表
接口访问日志表
CREATE TABLE demo.firewall_access_log (
id int8 NOT NULL, -- 主键ID
ip_address varchar(100) NOT NULL, -- IP地址
api_path varchar(200) NOT NULL, -- API路径
user_agent varchar(500) NULL, -- User-Agent
request_method varchar(10) NULL, -- 请求方法
status_code int4 NULL, -- 响应状态码
block_reason varchar(100) NULL, -- 拦截原因
request_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 请求时间
response_time int8 NULL, -- 响应时间(毫秒)
CONSTRAINT firewall_access_log_pkey PRIMARY KEY (id)
);
CREATE INDEX idx_api_time ON demo.firewall_access_log USING btree (api_path, request_time);
CREATE INDEX idx_ip_time ON demo.firewall_access_log USING btree (ip_address, request_time);
COMMENT ON TABLE demo.firewall_access_log IS '接口访问日志表';
-- Column comments
COMMENT ON COLUMN demo.firewall_access_log.id IS '主键ID';
COMMENT ON COLUMN demo.firewall_access_log.ip_address IS 'IP地址';
COMMENT ON COLUMN demo.firewall_access_log.api_path IS 'API路径';
COMMENT ON COLUMN demo.firewall_access_log.user_agent IS 'User-Agent';
COMMENT ON COLUMN demo.firewall_access_log.request_method IS '请求方法';
COMMENT ON COLUMN demo.firewall_access_log.status_code IS '响应状态码';
COMMENT ON COLUMN demo.firewall_access_log.block_reason IS '拦截原因';
COMMENT ON COLUMN demo.firewall_access_log.request_time IS '请求时间';
COMMENT ON COLUMN demo.firewall_access_log.response_time IS '响应时间(毫秒)';
接口限流规则表
CREATE TABLE demo.firewall_rule (
id int8 NOT NULL, -- 主键ID
rule_name varchar(100) NOT NULL, -- 规则名称
api_pattern varchar(200) NOT NULL, -- API路径匹配模式
qps_limit int4 DEFAULT 100 NULL, -- QPS限制
enabled bool DEFAULT true NULL, -- 是否启用
description varchar(500) NULL, -- 规则描述
created_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 创建时间
updated_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 更新时间
CONSTRAINT firewall_rule_pkey PRIMARY KEY (id)
);
COMMENT ON TABLE demo.firewall_rule IS '接口限流规则表';
-- Column comments
COMMENT ON COLUMN demo.firewall_rule.id IS '主键ID';
COMMENT ON COLUMN demo.firewall_rule.rule_name IS '规则名称';
COMMENT ON COLUMN demo.firewall_rule.api_pattern IS 'API路径匹配模式';
COMMENT ON COLUMN demo.firewall_rule.qps_limit IS 'QPS限制';
COMMENT ON COLUMN demo.firewall_rule.enabled IS '是否启用';
COMMENT ON COLUMN demo.firewall_rule.description IS '规则描述';
COMMENT ON COLUMN demo.firewall_rule.created_time IS '创建时间';
COMMENT ON COLUMN demo.firewall_rule.updated_time IS '更新时间';
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(1, '用户登录限流', '/api/auth/login', 10, true, '用户登录接口限流，防止暴力破解', '2026-01-26 13:48:18.421', '2026-01-26 13:48:18.421');
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(2, '订单接口限流', '/api/order/**', 50, true, '订单相关接口限流', '2026-01-26 13:48:18.421', '2026-01-26 13:48:18.421');
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(3, '支付接口限流', '/api/payment/**', 20, true, '支付相关接口限流', '2026-01-26 13:48:18.421', '2026-01-26 13:48:18.421');
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(4, '文件上传限流', '/api/upload/**', 30, true, '文件上传接口限流', '2026-01-26 13:48:18.421', '2026-01-26 13:48:18.421');
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(5, '数据导出限流', '/api/export/**', 5, true, '数据导出接口限流，防止大量导出', '2026-01-26 13:48:18.421', '2026-01-26 13:48:18.421');
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(6, '默认API限流', '/api/test/**', 10, true, '默认API接口限流规则', '2026-01-26 13:48:18.421', '2026-01-26 15:43:53.418');
INSERT INTO firewall_rule (id, rule_name, api_pattern, qps_limit, enabled, description, created_time, updated_time) VALUES(7, 'demo 限流', '/demo', 2, true, '默认API接口限流规则', '2026-01-26 13:48:18.421', '2026-01-26 15:43:53.418');
接口访问统计表
CREATE TABLE demo.firewall_statistics (
id int8 NOT NULL, -- 主键ID
stat_date date NOT NULL, -- 统计日期
api_path varchar(200) NOT NULL, -- API路径
total_requests int8 DEFAULT 0 NULL, -- 总请求数
blocked_requests int8 DEFAULT 0 NULL, -- 被拦截请求数
avg_response_time numeric(10, 2) DEFAULT 0 NULL, -- 平均响应时间
created_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 创建时间
updated_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 更新时间
CONSTRAINT firewall_statistics_pkey PRIMARY KEY (id),
CONSTRAINT uk_date_api UNIQUE (stat_date, api_path)
);
COMMENT ON TABLE demo.firewall_statistics IS '接口访问统计表';
-- Column comments
COMMENT ON COLUMN demo.firewall_statistics.id IS '主键ID';
COMMENT ON COLUMN demo.firewall_statistics.stat_date IS '统计日期';
COMMENT ON COLUMN demo.firewall_statistics.api_path IS 'API路径';
COMMENT ON COLUMN demo.firewall_statistics.total_requests IS '总请求数';
COMMENT ON COLUMN demo.firewall_statistics.blocked_requests IS '被拦截请求数';
COMMENT ON COLUMN demo.firewall_statistics.avg_response_time IS '平均响应时间';
COMMENT ON COLUMN demo.firewall_statistics.created_time IS '创建时间';
COMMENT ON COLUMN demo.firewall_statistics.updated_time IS '更新时间';
ip 黑名单表
CREATE TABLE demo.firewall_blacklist (
id int8 NOT NULL, -- 主键ID
ip_address varchar(100) NOT NULL, -- IP地址
reason varchar(200) NULL, -- 封禁原因
expire_time timestamp NULL, -- 过期时间(NULL表示永久)
enabled bool DEFAULT true NULL, -- 是否启用
created_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 创建时间
updated_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 更新时间
CONSTRAINT firewall_blacklist_pkey PRIMARY KEY (id),
CONSTRAINT uk_ip UNIQUE (ip_address)
);
COMMENT ON TABLE demo.firewall_blacklist IS 'ip 黑名单表';
-- Column comments
COMMENT ON COLUMN demo.firewall_blacklist.id IS '主键ID';
COMMENT ON COLUMN demo.firewall_blacklist.ip_address IS 'IP地址';
COMMENT ON COLUMN demo.firewall_blacklist.reason IS '封禁原因';
COMMENT ON COLUMN demo.firewall_blacklist.expire_time IS '过期时间(NULL表示永久)';
COMMENT ON COLUMN demo.firewall_blacklist.enabled IS '是否启用';
COMMENT ON COLUMN demo.firewall_blacklist.created_time IS '创建时间';
COMMENT ON COLUMN demo.firewall_blacklist.updated_time IS '更新时间';
INSERT INTO firewall_blacklist (id, ip_address, reason, expire_time, enabled, created_time, updated_time) VALUES(1, '10.163.193.196/32', '恶意攻击IP', NULL, NULL, '2026-01-26 13:57:46.428', '2026-01-26 15:35:34.028');
ip 白名单表
CREATE TABLE demo.firewall_whitelist (
id int8 NOT NULL, -- 主键ID
ip_address varchar(100) NOT NULL, -- IP地址
description varchar(200) NULL, -- 描述
enabled bool DEFAULT true NULL, -- 是否启用
created_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 创建时间
updated_time timestamp DEFAULT CURRENT_TIMESTAMP NULL, -- 更新时间
CONSTRAINT firewall_whitelist_pkey PRIMARY KEY (id),
CONSTRAINT uk_whitelist_ip UNIQUE (ip_address)
);
COMMENT ON TABLE demo.firewall_whitelist IS 'ip 白名单表';
-- Column comments
COMMENT ON COLUMN demo.firewall_whitelist.id IS '主键ID';
COMMENT ON COLUMN demo.firewall_whitelist.ip_address IS 'IP地址';
COMMENT ON COLUMN demo.firewall_whitelist.description IS '描述';
COMMENT ON COLUMN demo.firewall_whitelist.enabled IS '是否启用';
COMMENT ON COLUMN demo.firewall_whitelist.created_time IS '创建时间';
COMMENT ON COLUMN demo.firewall_whitelist.updated_time IS '更新时间';
INSERT INTO firewall_whitelist (id, ip_address, description, enabled, created_time, updated_time) VALUES(1, '127.0.0.1/32', '本地回环地址', true, '2026-01-26 13:48:35.552', '2026-01-26 13:48:35.552');
INSERT INTO firewall_whitelist (id, ip_address, description, enabled, created_time, updated_time) VALUES(2, '::1/128', 'IPv6本地回环地址', true, '2026-01-26 13:48:35.552', '2026-01-26 13:48:35.552');
INSERT INTO firewall_whitelist (id, ip_address, description, enabled, created_time, updated_time) VALUES(3, '192.168.1.100/32', '管理员IP地址', true, '2026-01-26 13:48:35.552', '2026-01-26 13:48:35.552');
配置文件
集成 postgresql+mybatis+firewall
# 数据库配置（PostgreSQL）
spring:
jackson:
# 核心基础配置
default-property-inclusion: non_null
date-format: yyyy-MM-dd HH:mm:ss
time-zone: Asia/Shanghai
datasource:
driver-class-name: org.postgresql.Driver
url: jdbc:postgresql://ip:port/db?currentSchema=public
username: username
password: password
hikari:
pool-name: uhaiinHikariPool
minimum-idle: 5
maximum-pool-size: 20
connection-timeout: 30000
idle-timeout: 600000
max-lifetime: 1800000
connection-test-query: SELECT 1
auto-commit: true
leak-detection-threshold: 60000
data-source-properties:
cachePrepStmts: true
useServerPrepStmts: true
prepStmtCacheSize: 250
prepStmtCacheSqlLimit: 2048
rewriteBatchedStatements: true
# MyBatis配置
mybatis:
mapper-locations:
- classpath:mapper/firewall/*.xml
- classpath:mapper/user/*.xml
type-aliases-package:
- com.uhaiin.firewall.entity
- com.uhaiin.user.entity
configuration:
map-underscore-to-camel-case: true
log-impl: org.apache.ibatis.logging.stdout.StdOutImpl # 生产关闭
# TKMyBatis（通用Mapper）配置
mapper:
mappers: tk.mybatis.mapper.common.Mapper # 指定通用Mapper接口，核心配置
identity: POSTGRESQL # 主键生成策略适配PostgreSQL（支持自增主键serial/bigserial）
not-empty: true # 更新时是否忽略空值（true：只更新非空字段，推荐）
style: camelhump # 字段名风格：驼峰（与mybatis的下划线转驼峰配合）
enable-method-cache: true # 开启方法缓存（可选）
# 管理端点配置
management:
endpoints:
web:
exposure:
include: health,info,metrics
endpoint:
health:
show-details: always
# 防火墙配置
firewall:
enabled: true
default-qps-limit: 100
cache-size: 1000
exclude-paths:
- /firewall/**
- /actuator/**
- /static/**
- /favicon.ico
核心代码
接口访问日志实体类
package com.uhaiin.firewall.entity;
import lombok.AllArgsConstructor;
import lombok.Builder;
import lombok.Data;
import lombok.NoArgsConstructor;
import javax.persistence.Column;
import javax.persistence.Id;
import javax.persistence.Table;
import java.time.LocalDateTime;
/**
* 表名：firewall_access_log
*/
@Table(name = "firewall_access_log")
@Data
@NoArgsConstructor
@AllArgsConstructor
@Builder
public class FirewallAccessLog {
/**
* 主键ID
*/
@Id
@Column(name = "id")
private Long id;
/**
* IP地址
*/
@Column(name = "ip_address")
private String ipAddress;
/**
* API路径
*/
@Column(name = "api_path")
private String apiPath;
/**
* User-Agent
*/
@Column(name = "user_agent")
private String userAgent;
/**
* 请求方法
*/
@Column(name = "request_method")
private String requestMethod;
/**
* 响应状态码
*/
@Column(name = "status_code")
private Integer statusCode;
/**
* 拦截原因
*/
@Column(name = "block_reason")
private String blockReason;
/**
* 请求时间
*/
@Column(name = "request_time")
private LocalDateTime requestTime;
/**
* 响应时间(毫秒)
*/
@Column(name = "response_time")
private Long responseTime;
/**
* 检查是否被拦截
*
* @return 是否被拦截
*/
public boolean isBlocked() {
return blockReason != null && !blockReason.trim().isEmpty();
}
/**
* 检查是否成功响应
*
* @return 是否成功
*/
public boolean isSuccess() {
return statusCode != null && statusCode >= 200 && statusCode < 300;
}
/**
* 获取响应时间描述
*
* @return 响应时间描述
*/
public String getResponseTimeDescription() {
if (responseTime == null) {
return "未知";
}
if (responseTime < 100) {
return "快速 (" + responseTime + "ms)";
} else if (responseTime < 500) {
return "正常 (" + responseTime + "ms)";
} else if (responseTime < 1000) {
return "较慢 (" + responseTime + "ms)";
} else {
return "缓慢 (" + responseTime + "ms)";
}
}
/**
* 获取状态描述
*
* @return 状态描述
*/
public String getStatusDescription() {
if (isBlocked()) {
return "已拦截: " + blockReason;
}
if (statusCode == null) {
return "未知";
}
return switch (statusCode) {
case 200 -> "成功";
case 400 -> "请求错误";
case 401 -> "未授权";
case 403 -> "禁止访问";
case 404 -> "未找到";
case 429 -> "请求过多";
case 500 -> "服务器错误";
default -> "状态码: " + statusCode;
};
}
}
ip 黑名单实体类
package com.uhaiin.firewall.entity;
import lombok.AllArgsConstructor;
import lombok.Builder;
import lombok.Data;
import lombok.NoArgsConstructor;
import javax.persistence.Column;
import javax.persistence.Id;
import javax.persistence.Table;
import java.time.LocalDateTime;
/**
* 表名：firewall_blacklist
*/
@Table(name = "firewall_blacklist")
@Data
@NoArgsConstructor
@AllArgsConstructor
@Builder
public class FirewallBlacklist {
/**
* 主键ID
*/
@Id
@Column(name = "id")
private Long id;
/**
* IP地址
*/
@Column(name = "ip_address")
private String ipAddress;
/**
* 封禁原因
*/
private String reason;
/**
* 过期时间(NULL表示永久)
*/
@Column(name = "expire_time")
private LocalDateTime expireTime;
/**
* 是否启用
*/
private Boolean enabled;
/**
* 创建时间
*/
@Column(name = "created_time")
private LocalDateTime createdTime;
/**
* 更新时间
*/
@Column(name = "updated_time")
private LocalDateTime updatedTime;
/**
* 检查IP是否已过期
*
* @return 是否已过期
*/
public boolean isExpired() {
return expireTime != null && LocalDateTime.now().isAfter(expireTime);
}
/**
* 检查IP是否有效（启用且未过期）
*
* @return 是否有效
*/
public boolean isValid() {
return (enabled == null || enabled) && !isExpired();
}
/**
* 检查IP地址是否匹配
*
* @param ip 要检查的IP地址
* @return 是否匹配
*/
public boolean matches(String ip) {
if (ipAddress == null || ip == null) {
return false;
}
// 支持CIDR格式的IP段匹配
if (ipAddress.contains("/")) {
return matchesCidr(ip, ipAddress);
}
// 支持通配符匹配
if (ipAddress.contains("*")) {
String pattern = ipAddress.replace("*", ".*");
return ip.matches(pattern);
}
// 精确匹配
return ipAddress.equals(ip);
}
/**
* CIDR格式IP段匹配
*
* @param ip IP地址
* @param cidr CIDR格式的IP段
* @return 是否匹配
*/
private boolean matchesCidr(String ip, String cidr) {
try {
String[] parts = cidr.split("/");
if (parts.length != 2) {
return false;
}
String networkIp = parts[0];
int prefixLength = Integer.parseInt(parts[1]);
// 简单的IPv4 CIDR匹配实现
long ipLong = ipToLong(ip);
long networkLong = ipToLong(networkIp);
long mask = (0xFFFFFFFFL << (32 - prefixLength)) & 0xFFFFFFFFL;
return (ipLong & mask) == (networkLong & mask);
} catch (Exception e) {
return false;
}
}
/**
* IP地址转换为长整型
*
* @param ip IP地址
* @return 长整型值
*/
private long ipToLong(String ip) {
String[] parts = ip.split("\\.");
if (parts.length != 4) {
throw new IllegalArgumentException("Invalid IP address: " + ip);
}
long result = 0;
for (int i = 0; i < 4; i++) {
result = (result << 8) + Integer.parseInt(parts[i]);
}
return result;
}
}
规则实体类
package com.uhaiin.firewall.entity;
import lombok.AllArgsConstructor;
import lombok.Builder;
import lombok.Data;
import lombok.NoArgsConstructor;
import javax.persistence.Column;
import javax.persistence.Id;
import javax.persistence.Table;
import java.time.LocalDateTime;
import java.util.List;
/**
* 表名：firewall_rule
*/
@Table(name = "firewall_rule")
@Data
@NoArgsConstructor
@AllArgsConstructor
@Builder
public class FirewallRule {
/**
* 主键ID
*/
@Id
@Column(name = "id")
private Long id;
/**
* 规则名称
*/
@Column(name = "rule_name")
private String ruleName;
/**
* API路径匹配模式
*/
@Column(name = "api_pattern")
private String apiPattern;
/**
* QPS限制
*/
@Column(name = "qps_limit")
private Integer qpsLimit;
/**
* 是否启用
*/
private Boolean enabled;
/**
* 规则描述
*/
private String description;
/**
* 创建时间
*/
@Column(name = "created_time")
private LocalDateTime createdTime;
/**
* 更新时间
*/
@Column(name = "updated_time")
private LocalDateTime updatedTime;
/**
* 黑名单IP列表（运行时使用，不存储在数据库）
*/
private List<String> blackIps;
/**
* 白名单IP列表（运行时使用，不存储在数据库）
*/
private List<String> whiteIps;
/**
* 检查API路径是否匹配此规则
*
* @param apiPath API路径
* @return 是否匹配
*/
public boolean matches(String apiPath) {
if (apiPattern == null || apiPath == null) {
return false;
}
// 支持通配符匹配
String pattern = apiPattern.replace("**", ".*").replace("*", "[^/]*");
return apiPath.matches(pattern);
}
/**
* 获取有效的QPS限制
*
* @return QPS限制，默认100
*/
public int getEffectiveQpsLimit() {
return qpsLimit != null && qpsLimit > 0 ? qpsLimit : 100;
}
/**
* 检查规则是否启用
*
* @return 是否启用，默认true
*/
public boolean isEffectiveEnabled() {
return enabled == null || enabled;
}
}
接口访问统计实体类
package com.uhaiin.firewall.entity;
import lombok.AllArgsConstructor;
import lombok.Builder;
import lombok.Data;
import lombok.NoArgsConstructor;
import javax.persistence.Column;
import javax.persistence.Id;
import javax.persistence.Table;
import java.math.BigDecimal;
import java.time.LocalDate;
import java.time.LocalDateTime;
/**
* 表名：firewall_statistics
*/
@Table(name = "firewall_statistics")
@Data
@NoArgsConstructor
@AllArgsConstructor
@Builder
public class FirewallStatistics {
/**
* 主键ID
*/
@Id
@Column(name = "id")
private Long id;
/**
* 统计日期
*/
@Column(name = "stat_date")
private LocalDate statDate;
/**
* API路径
*/
@Column(name = "api_path")
private String apiPath;
/**
* 总请求数
*/
@Column(name = "total_requests")
private Long totalRequests;
/**
* 被拦截请求数
*/
@Column(name = "blocked_requests")
private Long blockedRequests;
/**
* 平均响应时间
*/
@Column(name = "avg_response_time")
private BigDecimal avgResponseTime;
/**
* 创建时间
*/
@Column(name = "created_time")
private LocalDateTime createdTime;
/**
* 更新时间
*/
@Column(name = "updated_time")
private LocalDateTime updatedTime;
/**
* 计算拦截率
*
* @return 拦截率（百分比）
*/
public double getBlockRate() {
if (totalRequests == null || totalRequests == 0) {
return 0.0;
}
long blocked = blockedRequests != null ? blockedRequests : 0;
return (double) blocked / totalRequests * 100;
}
/**
* 计算成功率
*
* @return 成功率（百分比）
*/
public double getSuccessRate() {
return 100.0 - getBlockRate();
}
/**
* 获取拦截率描述
*
* @return 拦截率描述
*/
public String getBlockRateDescription() {
double rate = getBlockRate();
if (rate == 0) {
return "无拦截";
} else if (rate < 1) {
return "极低 (" + String.format("%.2f", rate) + "%)";
} else if (rate < 5) {
return "较低 (" + String.format("%.2f", rate) + "%)";
} else if (rate < 20) {
return "中等 (" + String.format("%.2f", rate) + "%)";
} else {
return "较高 (" + String.format("%.2f", rate) + "%)";
}
}
/**
* 获取响应时间描述
*
* @return 响应时间描述
*/
public String getResponseTimeDescription() {
if (avgResponseTime == null) {
return "未知";
}
double time = avgResponseTime.doubleValue();
if (time < 100) {
return "快速 (" + String.format("%.1f", time) + "ms)";
} else if (time < 500) {
return "正常 (" + String.format("%.1f", time) + "ms)";
} else if (time < 1000) {
return "较慢 (" + String.format("%.1f", time) + "ms)";
} else {
return "缓慢 (" + String.format("%.1f", time) + "ms)";
}
}
/**
* 增加请求统计
*
* @param isBlocked 是否被拦截
* @param responseTime 响应时间
*/
public void addRequest(boolean isBlocked, long responseTime) {
// 增加总请求数
this.totalRequests = (this.totalRequests != null ? this.totalRequests : 0) + 1;
// 增加拦截数
if (isBlocked) {
this.blockedRequests = (this.blockedRequests != null ? this.blockedRequests : 0) + 1;
}
// 更新平均响应时间
if (this.avgResponseTime == null) {
this.avgResponseTime = BigDecimal.valueOf(responseTime);
} else {
// 计算新的平均值
BigDecimal currentTotal = this.avgResponseTime.multiply(BigDecimal.valueOf(this.totalRequests - 1));
BigDecimal newTotal = currentTotal.add(BigDecimal.valueOf(responseTime));
this.avgResponseTime = newTotal.divide(BigDecimal.valueOf(this.totalRequests), 2, BigDecimal.ROUND_HALF_UP);
}
// 更新时间
this.updatedTime = LocalDateTime.now();
}
}
ip 白名单实体类
package com.uhaiin.firewall.entity;
import java.time.LocalDateTime;
import javax.persistence.Column;
import javax.persistence.Id;
import javax.persistence.Table;
import lombok.AllArgsConstructor;
import lombok.Builder;
import lombok.Data;
import lombok.NoArgsConstructor;
/**
* 表名：firewall_whitelist
*/
@Table(name = "firewall_whitelist")
@Data
@NoArgsConstructor
@AllArgsConstructor
@Builder
public class FirewallWhitelist {
/**
* 主键ID
*/
@Id
@Column(name = "id")
private Long id;
/**
* IP地址
*/
@Column(name = "ip_address")
private String ipAddress;
/**
* 描述
*/
private String description;
/**
* 是否启用
*/
private Boolean enabled;
/**
* 创建时间
*/
@Column(name = "created_time")
private LocalDateTime createdTime;
/**
* 更新时间
*/
@Column(name = "updated_time")
private LocalDateTime updatedTime;
/**
* 检查IP是否有效（启用）
*
* @return 是否有效
*/
public boolean isValid() {
return enabled == null || enabled;
}
/**
* 检查IP地址是否匹配
*
* @param ip 要检查的IP地址
* @return 是否匹配
*/
public boolean matches(String ip) {
if (ipAddress == null || ip == null) {
return false;
}
// 支持CIDR格式的IP段匹配
if (ipAddress.contains("/")) {
return matchesCidr(ip, ipAddress);
}
// 支持通配符匹配
if (ipAddress.contains("*")) {
String pattern = ipAddress.replace("*", ".*");
return ip.matches(pattern);
}
// 精确匹配
return ipAddress.equals(ip);
}
/**
* CIDR格式IP段匹配
*
* @param ip IP地址
* @param cidr CIDR格式的IP段
* @return 是否匹配
*/
private boolean matchesCidr(String ip, String cidr) {
try {
String[] parts = cidr.split("/");
if (parts.length != 2) {
return false;
}
String networkIp = parts[0];
int prefixLength = Integer.parseInt(parts[1]);
// 简单的IPv4 CIDR匹配实现
long ipLong = ipToLong(ip);
long networkLong = ipToLong(networkIp);
long mask = (0xFFFFFFFFL << (32 - prefixLength)) & 0xFFFFFFFFL;
return (ipLong & mask) == (networkLong & mask);
} catch (Exception e) {
return false;
}
}
/**
* IP地址转换为长整型
*
* @param ip IP地址
* @return 长整型值
*/
private long ipToLong(String ip) {
String[] parts = ip.split("\\.");
if (parts.length != 4) {
throw new IllegalArgumentException("Invalid IP address: " + ip);
}
long result = 0;
for (int i = 0; i < 4; i++) {
result = (result << 8) + Integer.parseInt(parts[i]);
}
return result;
}
}
mapper
采用通用mapper：tk.mybatis
import tk.mybatis.mapper.common.Mapper;
public interface FirewallAccessLogMapper extends Mapper<FirewallAccessLog> {}
public interface FirewallBlacklistMapper extends Mapper<FirewallBlacklist> {}
public interface FirewallRuleMapper extends Mapper<FirewallRule> {}
public interface FirewallStatisticsMapper extends Mapper<FirewallStatistics> {}
public interface FirewallWhitelistMapper extends Mapper<FirewallWhitelist> {}
WebConfig
import com.uhaiin.common.interceptor.FirewallInterceptor;
import jakarta.annotation.Resource;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.InterceptorRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurer;
import java.util.Arrays;
import java.util.List;
/**
* Web配置类
*
*/
@Configuration
public class WebConfig implements WebMvcConfigurer {
@Resource
private FirewallInterceptor firewallInterceptor;
@Value("${firewall.exclude-paths:/actuator/**,/static/**,/css/**,/js/**,/images/**,/favicon.ico}")
private String excludePathsStr;
@Override
public void addInterceptors(InterceptorRegistry registry) {
// 解析排除路径
List<String> excludePaths = Arrays.asList(excludePathsStr.split(","));
registry.addInterceptor(firewallInterceptor)
// 拦截所有请求
.addPathPatterns("/**")
// 排除指定路径
.excludePathPatterns(excludePaths);
}
}
Interceptor
package com.uhaiin.common.interceptor;
import com.fasterxml.jackson.databind.ObjectMapper;
import com.google.common.cache.Cache;
import com.google.common.cache.CacheBuilder;
import com.uhaiin.common.utils.SnowflakeIdGenerator;
import com.uhaiin.firewall.entity.FirewallAccessLog;
import com.uhaiin.firewall.entity.FirewallRule;
import com.uhaiin.firewall.service.FirewallService;
import com.uhaiin.firewall.service.RuleManagerService;
import jakarta.annotation.Resource;
import jakarta.servlet.http.HttpServletRequest;
import jakarta.servlet.http.HttpServletResponse;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Component;
import org.springframework.web.servlet.HandlerInterceptor;
import java.io.IOException;
import java.nio.charset.StandardCharsets;
import java.time.LocalDateTime;
import java.util.HashMap;
import java.util.Map;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.atomic.AtomicInteger;
/**
* 防火墙拦截器
*
*/
@Slf4j
@Component
public class FirewallInterceptor implements HandlerInterceptor {
private final ObjectMapper objectMapper = new ObjectMapper();
@Resource
private RuleManagerService ruleManagerService;
@Resource
private FirewallService firewallService;
@Value("${firewall.enabled:false}")
private boolean firewallEnable;
@Value("${firewall.default.qps-limit:100}")
private int defaultQpsLimit;
@Value("${firewall.cache-size:10000}")
private long maximumSize;
/**
* QPS限制缓存 - 存储每个IP+API的访问计数
*/
private final Cache<String, AtomicInteger> qpsCache = CacheBuilder.newBuilder().maximumSize(maximumSize)
.expireAfterWrite(1, TimeUnit.MINUTES).build();
@Override
public boolean preHandle(HttpServletRequest request, HttpServletResponse response, Object handler) {
// 设置字符集为UTF-8
response.setCharacterEncoding(StandardCharsets.UTF_8.name());
long startTime = System.currentTimeMillis();
String ipAddress = getClientIpAddress(request);
String apiPath = request.getRequestURI();
String userAgent = request.getHeader("User-Agent");
String method = request.getMethod();
if (!firewallEnable) {
// 没有启用防火墙则直接返回true不拦截
return true;
}
log.info("防火墙拦截检查: IP={}, API={}, Method={}", ipAddress, apiPath, method);
try {
// 1. 检查白名单
if (ruleManagerService.isWhitelisted(ipAddress)) {
log.info("IP {} 在白名单中，允许访问", ipAddress);
logAccess(ipAddress, apiPath, userAgent, method, 200, null, startTime);
return true;
}
// 2. 检查黑名单
if (ruleManagerService.isBlacklisted(ipAddress)) {
log.warn("IP {} 在黑名单中，拒绝访问", ipAddress);
blockRequest(response, "IP地址被列入黑名单", 403);
logAccess(ipAddress, apiPath, userAgent, method, 403, "IP黑名单拦截", startTime);
return false;
}
// 3. 获取匹配的防火墙规则
FirewallRule rule = ruleManagerService.getMatchingRule(apiPath);
if (rule == null) {
// 使用默认规则
rule = createDefaultRule(apiPath);
}
// 4. QPS限制检查
if (!checkQpsLimit(ipAddress, apiPath, rule)) {
log.warn("IP {} 访问 {} 超过QPS限制 {}", ipAddress, apiPath, rule.getEffectiveQpsLimit());
blockRequest(response, "访问频率过高，请稍后再试", 429);
logAccess(ipAddress, apiPath, userAgent, method, 429, "QPS限制拦截", startTime);
return false;
}
// 5. 记录正常访问
logAccess(ipAddress, apiPath, userAgent, method, 200, null, startTime);
log.info("IP {} 访问 {} 通过防火墙检查", ipAddress, apiPath);
return true;
} catch (Exception e) {
log.error("防火墙拦截器处理异常: IP={}, API={}", ipAddress, apiPath, e);
logAccess(ipAddress, apiPath, userAgent, method, 500, "系统异常", startTime);
// 异常情况下允许通过，避免影响正常业务
return true;
}
}
/**
* 检查QPS限制
*
* @param ipAddress IP地址
* @param apiPath API路径
* @param rule 防火墙规则
* @return 是否通过检查
*/
private boolean checkQpsLimit(String ipAddress, String apiPath, FirewallRule rule) {
String key = ipAddress + ":" + apiPath;
int qpsLimit = rule.getEffectiveQpsLimit();
if (qpsLimit <= 0) {
// 无限制
return true;
}
AtomicInteger counter = qpsCache.getIfPresent(key);
if (counter == null) {
counter = new AtomicInteger(0);
qpsCache.put(key, counter);
}
int currentCount = counter.incrementAndGet();
return currentCount <= qpsLimit;
}
/**
* 创建默认规则
*
* @param apiPath API路径
* @return 默认规则
*/
private FirewallRule createDefaultRule(String apiPath) {
FirewallRule rule = new FirewallRule();
rule.setRuleName("默认规则");
rule.setApiPattern(apiPath);
rule.setQpsLimit(defaultQpsLimit);
rule.setEnabled(true);
return rule;
}
/**
* 阻止请求并返回错误响应
*
* @param response HTTP响应
* @param message 错误消息
* @param statusCode 状态码
* @throws IOException IO异常
*/
private void blockRequest(HttpServletResponse response, String message, int statusCode) throws IOException {
response.setStatus(statusCode);
response.setContentType("application/json;charset=UTF-8");
Map<String, Object> result = new HashMap<>();
result.put("success", false);
result.put("code", statusCode);
result.put("message", message);
result.put("timestamp", System.currentTimeMillis());
String jsonResponse = objectMapper.writeValueAsString(result);
response.getWriter().write(jsonResponse);
response.getWriter().flush();
}
/**
* 记录访问日志
*
* @param ipAddress IP地址
* @param apiPath API路径
* @param userAgent User-Agent
* @param method 请求方法
* @param statusCode 状态码
* @param blockReason 拦截原因
* @param startTime 开始时间
*/
private void logAccess(String ipAddress, String apiPath, String userAgent, String method, int statusCode,
String blockReason, long startTime) {
try {
FirewallAccessLog accessLog = new FirewallAccessLog();
accessLog.setId(SnowflakeIdGenerator.next());
accessLog.setIpAddress(ipAddress);
accessLog.setApiPath(apiPath);
accessLog.setUserAgent(userAgent);
accessLog.setRequestMethod(method);
accessLog.setStatusCode(statusCode);
accessLog.setBlockReason(blockReason);
accessLog.setRequestTime(LocalDateTime.now());
accessLog.setResponseTime(System.currentTimeMillis() - startTime);
// 异步记录日志，避免影响性能
firewallService.logAccessAsync(accessLog);
} catch (Exception e) {
log.error("记录访问日志失败: IP={}, API={}", ipAddress, apiPath, e);
}
}
/**
* 获取客户端真实IP地址
*
* @param request HTTP请求
* @return IP地址
*/
private String getClientIpAddress(HttpServletRequest request) {
String[] headers = {"X-Forwarded-For", "X-Real-IP", "Proxy-Client-IP", "WL-Proxy-Client-IP",
"HTTP_X_FORWARDED_FOR", "HTTP_X_FORWARDED", "HTTP_X_CLUSTER_CLIENT_IP", "HTTP_CLIENT_IP",
"HTTP_FORWARDED_FOR", "HTTP_FORWARDED", "HTTP_VIA", "REMOTE_ADDR"};
for (String header : headers) {
String ip = request.getHeader(header);
if (ip != null && !ip.isEmpty() && !"unknown".equalsIgnoreCase(ip)) {
// 多个IP时取第一个
if (ip.contains(",")) {
ip = ip.split(",")[0].trim();
}
return ip;
}
}
return request.getRemoteAddr();
}
}
实现类
防火墙实现类
package com.uhaiin.firewall.service.impl;
import com.uhaiin.common.utils.SnowflakeIdGenerator;
import com.uhaiin.firewall.entity.FirewallAccessLog;
import com.uhaiin.firewall.entity.FirewallStatistics;
import com.uhaiin.firewall.mapper.FirewallAccessLogMapper;
import com.uhaiin.firewall.mapper.FirewallStatisticsMapper;
import com.uhaiin.firewall.service.FirewallService;
import jakarta.annotation.Resource;
import lombok.extern.slf4j.Slf4j;
import org.springframework.scheduling.annotation.Async;
import org.springframework.stereotype.Service;
import org.springframework.transaction.annotation.Transactional;
import tk.mybatis.mapper.entity.Example;
import tk.mybatis.mapper.entity.Example.Criteria;
import java.math.BigDecimal;
import java.time.LocalDate;
import java.time.LocalDateTime;
@Slf4j
@Service
public class FirewallServiceImpl implements FirewallService {
@Resource
private FirewallAccessLogMapper accessLogMapper;
@Resource
private FirewallStatisticsMapper statisticsMapper;
/**
* 异步记录访问日志
*
* @param accessLog 访问日志
*/
@Override
@Async
@Transactional
public void logAccessAsync(FirewallAccessLog accessLog) {
try {
accessLogMapper.insert(accessLog);
// 更新统计数据
updateStatistics(accessLog);
} catch (Exception e) {
log.error("异步记录访问日志失败: {}", accessLog, e);
}
}
/**
* 更新统计数据
*
* @param accessLog 访问日志
*/
private void updateStatistics(FirewallAccessLog accessLog) {
try {
LocalDate today = LocalDate.now();
String apiPath = accessLog.getApiPath();
// 查询今日统计
Example example = new Example(FirewallStatistics.class);
Criteria criteria = example.createCriteria();
criteria.andEqualTo("statDate", today).andEqualTo("apiPath", apiPath);
FirewallStatistics stats = statisticsMapper.selectOneByExample(example);
if (stats == null) {
// 创建新的统计记录
stats = new FirewallStatistics();
stats.setId(SnowflakeIdGenerator.next());
stats.setStatDate(today);
stats.setApiPath(apiPath);
stats.setTotalRequests(1L);
stats.setBlockedRequests(accessLog.isBlocked() ? 1L : 0L);
stats.setAvgResponseTime(BigDecimal.valueOf(accessLog.getResponseTime()));
stats.setCreatedTime(LocalDateTime.now());
stats.setUpdatedTime(LocalDateTime.now());
statisticsMapper.insert(stats);
} else {
// 更新现有统计记录
stats.addRequest(accessLog.isBlocked(), accessLog.getResponseTime());
stats.setUpdatedTime(LocalDateTime.now());
statisticsMapper.updateByPrimaryKeySelective(stats);
}
} catch (Exception e) {
log.error("更新统计数据失败: {}", accessLog, e);
}
}
}
规则实现类
package com.uhaiin.firewall.service.impl;
import com.uhaiin.firewall.entity.FirewallBlacklist;
import com.uhaiin.firewall.entity.FirewallRule;
import com.uhaiin.firewall.entity.FirewallWhitelist;
import com.uhaiin.firewall.mapper.FirewallBlacklistMapper;
import com.uhaiin.firewall.mapper.FirewallRuleMapper;
import com.uhaiin.firewall.mapper.FirewallWhitelistMapper;
import com.uhaiin.firewall.service.RuleManagerService;
import jakarta.annotation.PostConstruct;
import jakarta.annotation.Resource;
import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Service;
import tk.mybatis.mapper.entity.Example;
import tk.mybatis.mapper.entity.Example.Criteria;
import java.time.LocalDateTime;
import java.util.List;
import java.util.Map;
import java.util.concurrent.ConcurrentHashMap;
import java.util.stream.Collectors;
@Slf4j
@Service
public class RuleManagerServiceImpl implements RuleManagerService {
/**
* 规则缓存
*/
private final Map<String, FirewallRule> ruleCache = new ConcurrentHashMap<>();
/**
* 黑名单缓存
*/
private final Map<String, FirewallBlacklist> blacklistCache = new ConcurrentHashMap<>();
/**
* 白名单缓存
*/
private final Map<String, FirewallWhitelist> whitelistCache = new ConcurrentHashMap<>();
@Resource
private FirewallRuleMapper ruleMapper;
@Resource
private FirewallBlacklistMapper blacklistMapper;
@Resource
private FirewallWhitelistMapper whitelistMapper;
/**
* 初始化加载规则
*/
@PostConstruct
public void init() {
log.info("初始化防火墙规则管理器...");
refreshRules();
refreshBlacklist();
refreshWhitelist();
log.info("防火墙规则管理器初始化完成，加载规则: {}, 黑名单: {}, 白名单: {}", ruleCache.size(), blacklistCache.size(),
whitelistCache.size());
}
/**
* 获取匹配指定API路径的规则
*
* @param apiPath API路径
* @return 匹配的规则，如果没有匹配则返回null
*/
@Override
public FirewallRule getMatchingRule(String apiPath) {
if (apiPath == null) {
return null;
}
// 优先精确匹配
FirewallRule exactMatch = ruleCache.get(apiPath);
if (exactMatch != null && exactMatch.isEffectiveEnabled()) {
return exactMatch;
}
// 模式匹配
for (FirewallRule rule : ruleCache.values()) {
if (rule.isEffectiveEnabled() && rule.matches(apiPath)) {
return rule;
}
}
return null;
}
/**
* 检查IP是否在黑名单中
*
* @param ipAddress IP地址
* @return 是否在黑名单中
*/
@Override
public boolean isBlacklisted(String ipAddress) {
if (ipAddress == null) {
return false;
}
// 精确匹配
FirewallBlacklist exactMatch = blacklistCache.get(ipAddress);
if (exactMatch != null && exactMatch.isValid()) {
return true;
}
// 模式匹配
for (FirewallBlacklist blacklist : blacklistCache.values()) {
if (blacklist.isValid() && blacklist.matches(ipAddress)) {
return true;
}
}
return false;
}
/**
* 检查IP是否在白名单中
*
* @param ipAddress IP地址
* @return 是否在白名单中
*/
@Override
public boolean isWhitelisted(String ipAddress) {
if (ipAddress == null) {
return false;
}
// 精确匹配
FirewallWhitelist exactMatch = whitelistCache.get(ipAddress);
if (exactMatch != null && exactMatch.isValid()) {
return true;
}
// 模式匹配
for (FirewallWhitelist whitelist : whitelistCache.values()) {
if (whitelist.isValid() && whitelist.matches(ipAddress)) {
return true;
}
}
return false;
}
/**
* 获取所有规则
*
* @return 规则列表
*/
@Override
public List<FirewallRule> getAllRules() {
Example example = new Example(FirewallRule.class);
example.orderBy("id").asc();
return ruleMapper.selectByExample(example);
}
/**
* 获取所有黑名单
*
* @return 黑名单列表
*/
@Override
public List<FirewallBlacklist> getAllBlacklist() {
Example example = new Example(FirewallBlacklist.class);
example.orderBy("id").asc();
return blacklistMapper.selectByExample(example);
}
/**
* 获取所有白名单
*
* @return 白名单列表
*/
@Override
public List<FirewallWhitelist> getAllWhitelist() {
Example example = new Example(FirewallWhitelist.class);
example.orderBy("id").asc();
return whitelistMapper.selectByExample(example);
}
/**
* 添加或更新规则
*
* @param rule 规则
* @return 是否成功
*/
@Override
public boolean saveRule(FirewallRule rule) {
try {
if (rule.getId() == null) {
ruleMapper.insert(rule);
} else {
ruleMapper.updateByPrimaryKeySelective(rule);
}
refreshRules();
log.info("规则保存成功: {}", rule.getRuleName());
return true;
} catch (Exception e) {
log.error("规则保存失败: {}", rule.getRuleName(), e);
return false;
}
}
/**
* 删除规则
*
* @param id 规则ID
* @return 是否成功
*/
@Override
public boolean deleteRule(Long id) {
try {
ruleMapper.deleteByPrimaryKey(id);
refreshRules();
log.info("规则删除成功: {}", id);
return true;
} catch (Exception e) {
log.error("规则删除失败: {}", id, e);
return false;
}
}
/**
* 添加黑名单
*
* @param blacklist 黑名单
* @return 是否成功
*/
@Override
public boolean addBlacklist(FirewallBlacklist blacklist) {
try {
blacklistMapper.insert(blacklist);
refreshBlacklist();
log.info("黑名单添加成功: {}", blacklist.getIpAddress());
return true;
} catch (Exception e) {
log.error("黑名单添加失败: {}", blacklist.getIpAddress(), e);
return false;
}
}
/**
* 删除黑名单
*
* @param id 黑名单ID
* @return 是否成功
*/
@Override
public boolean deleteBlacklist(Long id) {
try {
blacklistMapper.deleteByPrimaryKey(id);
refreshBlacklist();
log.info("黑名单删除成功: {}", id);
return true;
} catch (Exception e) {
log.error("黑名单删除失败: {}", id, e);
return false;
}
}
/**
* 添加白名单
*
* @param whitelist 白名单
* @return 是否成功
*/
@Override
public boolean addWhitelist(FirewallWhitelist whitelist) {
try {
whitelistMapper.insert(whitelist);
refreshWhitelist();
log.info("白名单添加成功: {}", whitelist.getIpAddress());
return true;
} catch (Exception e) {
log.error("白名单添加失败: {}", whitelist.getIpAddress(), e);
return false;
}
}
/**
* 删除白名单
*
* @param id 白名单ID
* @return 是否成功
*/
@Override
public boolean deleteWhitelist(Long id) {
try {
whitelistMapper.deleteByPrimaryKey(id);
refreshWhitelist();
log.info("白名单删除成功: {}", id);
return true;
} catch (Exception e) {
log.error("白名单删除失败: {}", id, e);
return false;
}
}
/**
* 更新黑名单
*
* @param blacklist 黑名单
* @return 是否成功
*/
@Override
public boolean updateBlacklist(FirewallBlacklist blacklist) {
try {
blacklistMapper.updateByPrimaryKeySelective(blacklist);
refreshBlacklist();
log.info("黑名单更新成功: {}", blacklist.getIpAddress());
return true;
} catch (Exception e) {
log.error("黑名单更新失败: {}", blacklist.getIpAddress(), e);
return false;
}
}
/**
* 更新白名单
*
* @param whitelist 白名单
* @return 是否成功
*/
@Override
public boolean updateWhitelist(FirewallWhitelist whitelist) {
try {
whitelistMapper.updateByPrimaryKeySelective(whitelist);
refreshWhitelist();
log.info("白名单更新成功: {}", whitelist.getIpAddress());
return true;
} catch (Exception e) {
log.error("白名单更新失败: {}", whitelist.getIpAddress(), e);
return false;
}
}
/**
* 刷新规则缓存
*/
@Override
public void refreshRules() {
try {
Example example = new Example(FirewallRule.class);
Criteria criteria = example.createCriteria();
criteria.andEqualTo("enabled", true);
// 添加排序
example.orderBy("id").asc();
List<FirewallRule> rules = ruleMapper.selectByExample(example);
ruleCache.clear();
ruleCache.putAll(rules.stream().collect(Collectors.toMap(FirewallRule::getApiPattern, rule -> rule,
(oldBlackList, newBlackList) -> newBlackList)));
log.debug("规则缓存刷新完成，共加载 {} 条规则", ruleCache.size());
} catch (Exception e) {
log.error("刷新规则缓存失败", e);
}
}
/**
* 刷新黑名单缓存
*/
@Override
public void refreshBlacklist() {
try {
Example example = new Example(FirewallBlacklist.class);
Criteria criteria = example.createCriteria();
criteria.andEqualTo("enabled", true).andCondition("expire_time IS NULL OR expire_time > ",
LocalDateTime.now());
example.orderBy("id").asc();
List<FirewallBlacklist> blacklists = blacklistMapper.selectByExample(example);
blacklistCache.clear();
blacklistCache.putAll(blacklists.stream().collect(Collectors.toMap(FirewallBlacklist::getIpAddress,
blacklist -> blacklist, (oldBlackList, newBlackList) -> newBlackList)));
log.debug("黑名单缓存刷新完成，共加载 {} 条记录", blacklistCache.size());
} catch (Exception e) {
log.error("刷新黑名单缓存失败", e);
}
}
/**
* 刷新白名单缓存
*/
@Override
public void refreshWhitelist() {
try {
Example example = new Example(FirewallWhitelist.class);
Criteria criteria = example.createCriteria();
criteria.andEqualTo("enabled", true);
example.orderBy("id").asc();
List<FirewallWhitelist> whitelists = whitelistMapper.selectByExample(example);
whitelistCache.clear();
whitelistCache.putAll(whitelists.stream().collect(Collectors.toMap(FirewallWhitelist::getIpAddress,
whitelist -> whitelist, (oldBlackList, newBlackList) -> newBlackList)));
log.debug("白名单缓存刷新完成，共加载 {} 条记录", whitelistCache.size());
} catch (Exception e) {
log.error("刷新白名单缓存失败", e);
}
}
}
定时任务
定期清理过期规则
package com.uhaiin.firewall.scheduled;
import com.uhaiin.firewall.entity.FirewallAccessLog;
import com.uhaiin.firewall.entity.FirewallBlacklist;
import com.uhaiin.firewall.mapper.FirewallAccessLogMapper;
import com.uhaiin.firewall.mapper.FirewallBlacklistMapper;
import com.uhaiin.firewall.service.RuleManagerService;
import jakarta.annotation.Resource;
import lombok.extern.slf4j.Slf4j;
import org.springframework.context.annotation.Configuration;
import org.springframework.scheduling.annotation.EnableScheduling;
import org.springframework.scheduling.annotation.Scheduled;
import org.springframework.stereotype.Component;
import org.springframework.transaction.annotation.Transactional;
import tk.mybatis.mapper.entity.Example;
import tk.mybatis.mapper.entity.Example.Criteria;
import java.time.LocalDate;
import java.time.LocalDateTime;
@Component
@Configuration
@EnableScheduling
@Slf4j
public class FirewallTask {
@Resource
private FirewallAccessLogMapper accessLogMapper;
@Resource
private RuleManagerService ruleManagerService;
@Resource
private FirewallBlacklistMapper firewallBlacklistMapper;
/**
* 定时清理旧的访问日志（每天凌晨2点执行）
*/
@Transactional
@Scheduled(cron = "0 0 2 * * ?")
void cleanOldAccessLogs() {
try {
// 保留30天
LocalDateTime cutoffTime = LocalDateTime.now().minusDays(30);
Example example = new Example(FirewallAccessLog.class);
Criteria criteria = example.createCriteria();
criteria.andLessThan("requestTime", cutoffTime);
int deleted = accessLogMapper.deleteByExample(example);
log.info("清理30天前的访问日志，删除 {} 条记录", deleted);
} catch (Exception e) {
log.error("清理旧访问日志失败", e);
}
}
/**
* 定时清理旧的统计数据（每天凌晨3点执行）
*/
@Transactional
@Scheduled(cron = "0 0 3 * * ?")
void cleanOldStatistics() {
try {
// 保留90天
LocalDate cutoffDate = LocalDate.now().minusDays(90);
Example example = new Example(FirewallAccessLog.class);
Criteria criteria = example.createCriteria();
criteria.andLessThan("requestTime", cutoffDate);
int deleted = accessLogMapper.deleteByExample(example);
log.info("清理90天前的统计数据，删除 {} 条记录", deleted);
} catch (Exception e) {
log.error("清理旧统计数据失败", e);
}
}
/**
* 定时刷新缓存（每5分钟）
*/
@Scheduled(fixedRate = 5 * 60 * 1000)
@Transactional
public void scheduledRefresh() {
ruleManagerService.refreshRules();
ruleManagerService.refreshBlacklist();
ruleManagerService.refreshWhitelist();
// 清理过期的黑名单
try {
LocalDateTime now = LocalDateTime.now();
Example example = new Example(FirewallBlacklist.class);
Example.Criteria criteria = example.createCriteria();
criteria.andLessThanOrEqualTo("expireTime", now);
int cleaned = firewallBlacklistMapper.deleteByExample(example);
if (cleaned > 0) {
log.info("清理过期黑名单 {} 条", cleaned);
ruleManagerService.refreshBlacklist();
}
} catch (Exception e) {
log.error("清理过期黑名单失败", e);
}
}
}
POM
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>
<parent>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-parent</artifactId>
<version>4.0.0</version>
<relativePath/> <!-- lookup parent from repository -->
</parent>
<groupId>com.uhaiin</groupId>
<artifactId>demo</artifactId>
<version>0.0.1</version>
<name>demo</name>
<description>A bug in the code is worth two in the documentation</description>
<properties>
<java.version>21</java.version>
</properties>
<dependencies>
<!--启动器-->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter</artifactId>
</dependency>
<!--web-->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-web</artifactId>
</dependency>
<!-- Spring Boot Starter Actuator -->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-actuator</artifactId>
</dependency>
<!--测试套件-->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-test</artifactId>
<scope>test</scope>
</dependency>
<!--自动配置类-->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-autoconfigure</artifactId>
</dependency>
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-configuration-processor</artifactId>
<optional>true</optional>
</dependency>
<!--预编译工具-->
<dependency>
<groupId>org.projectlombok</groupId>
<artifactId>lombok</artifactId>
<optional>true</optional>
</dependency>
<!--热部署工具-->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-devtools</artifactId>
<scope>runtime</scope>
<optional>true</optional>
</dependency>
<!-- PostgreSQL 驱动 -->
<dependency>
<groupId>org.postgresql</groupId>
<artifactId>postgresql</artifactId>
<scope>runtime</scope>
</dependency>
<!--通用Mapper4之tk.mybatis-->
<dependency>
<groupId>tk.mybatis</groupId>
<artifactId>mapper</artifactId>
<version>4.3.0</version>
</dependency>
<!-- MyBatis Spring Boot Starter -->
<dependency>
<groupId>org.mybatis.spring.boot</groupId>
<artifactId>mybatis-spring-boot-starter</artifactId>
<version>4.0.1</version>
</dependency>
<!-- fastjson2 -->
<dependency>
<groupId>com.alibaba.fastjson2</groupId>
<artifactId>fastjson2</artifactId>
<version>2.0.60</version>
</dependency>
<!-- Jackson (JSON处理) -->
<dependency>
<groupId>com.fasterxml.jackson.core</groupId>
<artifactId>jackson-databind</artifactId>
</dependency>
<!-- Guava (限流器) -->
<dependency>
<groupId>com.google.guava</groupId>
<artifactId>guava</artifactId>
<version>33.5.0-jre</version>
<exclusions>
<exclusion>
<artifactId>checker-qual</artifactId>
<groupId>org.checkerframework</groupId>
</exclusion>
</exclusions>
</dependency>
</dependencies>
<build>
<plugins>
<plugin>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-maven-plugin</artifactId>
<configuration>
<excludeDevtools>true</excludeDevtools>
<excludes>
<exclude>
<groupId>org.projectlombok</groupId>
<artifactId>lombok</artifactId>
</exclude>
</excludes>
</configuration>
</plugin>
</plugins>
</build>
</project>
-
-
-
-
Touch background to close
uhaiin.com
